Encoder 6mm Shaft 600P/R Incremental Rotary AB Phase For Length Measurement ED

600P/R Rotary Encoder, Aideepen AB 2 Phase Incremental Rotary Encoder 6mm Shaft 5V-24V Wide Voltage Aideepen AB 2 Phase Incremental Rotary Encoder 600P/R Rotary Encoder 600 p/r (Single-phase 600 pulses /R,Two phase 4 frequency doubling to 2400 pulses) Power source: DC5-24V Shaft: 6*13mm/0.23*0.51 Size: 38*35.5mm/1.49*1.39 Output :AB 2phase output rectangular orthogonal pulse circuit, the output for the NPN open collector output type Notice:AB 2phase output must not be directly connected with VCC, otherwise, will burn the output triode, because different batches, and may not have the terminal Suitable for intelligent control of various displacement measurement, automatic fixed-length leather automatic guillotine machines, steel cut length control, civil measured height human scale, Students racing robotsEncoder size :38*35.5mm/1.49*1.39Shaft :about 6*13mm/0.23*0.51 Note: AB two -phase outputs must not be connected directly to Vcc, otherwise, they will burn the output transistor 【High quality】Aideepen Incremental rotary encoders 600 p/r (Single-phase 600 pulses /R,Two phase 4 frequency doubling to 2400 pulses). Main function: to measure the rotational speed, Angle and acceleration of the object and the length measurement Connection: Green = A phase, white = B phase, red = Vcc power +, black = V0. Note: AB two -phase outputs must not be connected directly to VCC, otherwise, they will burn the output transistor Parameters: power source: DC 5-24V; encoder size: 38*35.5mm/1.49*1.39; Shaft: about 6*13mm/0.23*0.51; maximum mechanical speed: 5000 R / min
