RIH 3/8NPT Air Filter Pressure Regulator Combo Piggyback, 5 Micron Brass Element, Poly Bowl, Semi-Auto Drain, Metal Bracket, 0-150 Psi Gauge Air Tool Compressor Filter

Prepare All calibrated components should meet the maximum flow requirements. Note that the airflow direction and arrows on the product body are pointing correctly, and that the port and thread sizes match. Pressure Regulation Pull up the pressure gauge knob and turn: If you turn clockwise, the pressure will rise steadily. As you turn counterclockwise, the pressure drops. Dial to read Make sure that the pressure gauge is tightly mounted on the main body, and pay attention to whether the reading rises and falls smoothly when adjusting the pressure. Drainage The drainage column is automatically discharged without pressure, and the air flow is closed when passing through. When the water level exceeds the upper limit, it must be drained, otherwise it will lead to poor dehumidification. The Story Of Right Pneumatic RIH Pneumatic was established in 2003. The company's main products are: air source processing components, actuators, cylinders, solenoid valves, etc. Our company is constantly improving and improving, with advanced product design, simple structure, beautiful appearance and long service life. Max working pressure: 145PSI(10.3BAR) Operating Temperature Range: 40-140F(5-60℃) Drain type: Manual 1 x 3 in 1 1/4'' Air Filter Pressure Regulator 1 x Pressure gauge 1 × Teflon Tape 【Working Temperature】 32-140℉；Maximum Pressure：0-145Psi (0-10 Bar)；Material：Body Material: Aluminum；Filter Element：5 Micron Brass Filter 【Features】To lower or maintain air pressure; Filter moisture and fine particles from the air. 5 Micron Brass Filter Element, Excellent Filtering Performance, Much Longer Life and Reuse Feasibility
