Introducing The RF Explorer Spectrum Analyzer Product Family: Empowering RF Analysis With Advanced Tools - Seeed Studio Product Catalog

It represents the culmination of more than 15 years of experience in developing robust RF high-frequency instruments that are both cost-sensitive and widely utilized worldwide. Equipped with advanced modes like Zero Span, Waterfall 2D and 3D, and Power Channel, this analyzer offers enhanced flexibility to effectively handle a wide range of scenarios. Its advanced power meter offers continuous and trigger modes for precise power measurement and analysis, with the trigger mode enabling the accurate capture of pulse and fast events that may be challenging to capture using other methods. Additionally, the cable tester allows for instant and easy checks of RF cables, ensuring their proper functioning. Configurable radio standards enable easy channel measurements to match specific radio standards, ensuring compatibility and accuracy. Note that displaying geolocated data positions on a map currently requires a computer connected to the Internet. The WiFi analyzer capability allows the detection of signals present on any 2.4/5.8GHz band channel, facilitating accurate identification of interference, collisions, and noise in WiFi environments. The device offers the ability to automatically save scan data on RAM for easy replay of any event. The captured data can also be manually or automatically saved in binary and CSV formats for later use. Continuous monitoring and alerting ensure that users stay informed with reliable alerts, including configurable limit lines, to ensure critical events are not missed. Seamless data export to USB drives is supported, allowing all captured data to be easily transferred and used in other software applications such as WSM, WWB6, Excel, or Matlab. Application Multimedia and Wireless Audio Telecommunications and communications Wireless network deployment and optimization IoT RF security and surveillance [Impressive frequency range] – Scan and diagnose any frequency starting in low frequency 50KHz up to high frequency 6.1GHz, with no gaps or limitations. Offering this wide operating range, it can detect all WiFi, cell stations and phones, IoT, HAM bands, Digital radio and TV, ISM bands, Drone links and pretty much all wireless technologies used in todays demanding communications world. [Robust design and instant power up] – A fully armored metallic enclosure provides robust mechanical strength and the high quality baked varnished paint provides a unique glossy finish. The device is designed and manufactured to last many years of demanding usage in the field, with internal rechargeable Lithium battery for hours of continuous usage. [Advanced features] – Included advanced high-resolution Spectrum Analyzer mode, WiFi Analyzer mode, Tracking SNA. [Free Computer software] - When connected to a Windows, Linux or Mac computer the analyzer can display advanced high resolution graphics, including Power Meter and Spectrum Analyzer real time charts, historical charts, save data to CSV files and export to other tools such as WW6 or MatLab, define markers and limit lines and much more. Free open source API and libraries are available to customize your own applications and services. [Tracking mode enabled] – When combined with RF Explorer Signal Generator the analyzer can perform full tracking SNA to define Gain, Attenuation and SWR for 1 and 2 port RF devices such as filters, amplifiers and antennas.
